| Physical Characteristics | |
| Dimensions | 160.0 x 76.0 x 15.5 / 17.0 mm / 6.3 x 2.99 x 0.61 / 0.67 in. |
| Weight | Android 9:287g / 10.12oz. (device with battery)657g / 23.17oz. (with battery, UHF 1, UHF back clip)798g / 28.15oz. (with battery, UHF 2, C66+R6) |
| Android 11:287g / 10.12 oz.(device with battery) 297g / 10.47oz.(device with battery, Fingerprint / Volume Measurement /Built-in UHF) | |
| Keypad | 1 power key, 2 scan keys, 2 volume keys |
| Battery | Removable main battery (normal version:4420 mAh ; Android 11 with fingerprint / built-in UHF / volume measurement version: 5200mAh ) |
| 5200 mAh optional pistol battery, support QC3.0 and RTC | |
| Standby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h) | |
| Continuous use: over 12 hours (depending on user environment) | |
| Charging time: 2.5 hours (charge device by standard adaptor and USB cable) | |
| Display | 5.5-inch high definition full display (18:9), IPS IGZO 1440 x 720 |
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Sensor | Accelerometer sensor, light sensor, proximity sensor, gravity sensor |
| Notification | Sound, LED indicator, vibrator |
| Audio | 2 microphones, 1 for noise cancellation; 1 speaker; receiver |
| Card slot | 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card |
| Interfaces | Android 9: USB Type-C, USB 3.0, OTG, extended thimble;Android 11: USB Type-C, USB 3.1, OTG, extended thimble; |
| WLAN | Support 802.11 a/b/g/n/ac/ax-ready/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4,IPV6, 5G PA; |
| Fast roaming: PMKID caching, 802.11r, OKC | |
| Operating Channels: 2.4G(channel 1~13),5G(channel36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132,136,140,144,149,153,157,161,165), Depends on local regulations | |
| Security and Encryption: WEP, WPA/WPA2-PSK(TKIP and AES), WAPI-PSK—EAP-TTLS, EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc. | |
| WWAN(Europe, Asia) | 2G: 850/900/1800/1900 MHz |
| 3G: CDMA EVDO: BC0 | |
| WCDMA: 850/900/1900/2100MHz | |
| TD-SCDMA: A/F(B34/B39) | |
| 4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41 | |
| WWAN(America) | 2G: 850/900/1800/1900 MHz |
| 3G: 850/900/1900/2100 MHz | |
| 4G: Android 9: B2/B4/B5/B7/B12/B17/B38 Android 11: B2/B4/B5/B7/B8/B12/B13/B17/B28A/B28B/B38 | |
| Data Collection | |
| Camera | |
| Rear Camera | Rear 13MP Autofocus with flash |
| NFC | |
| Frequency | 13.56 MHz |
| Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. |
| Chips | M1 card (S50, S70), CPU card, NFC tags, etc. |
| Range | 2-4 cm |
| Performance | |
| CPU | Android 9: Qualcomm Snapdragon™ 450 Octa-core, 1.8 GHz Android 11: Qualcomm Snapdragon™ 662 Octa-core, 2.0 GHz |
| RAM+ROM | 3 GB + 32 GB / 4 GB + 64 GB |
| Expansion | Supports up to 128 GB Micro SD card |
| Developing Environment | |
| Operating System | Android 9; GMS, 90-day security updates, Android EnterpriseRecommended, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported |
| Android 11; GMS, 90-day security updates, Android EnterpriseRecommended, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported. Committed support for a future upgrade to Android 12, 13, and Android 14 pending feasibility | |
| SDK | Chainway Software Development Kit |
| Language | Java |
| Tool | Eclipse / Android Studio |
| User Environment | |
| Operating Temp. | -4oF to 122oF / -20 ℃ to +50 ℃ |
| Storage Temp. | -40oF to 158oF / -40 ℃ to +70 ℃ |
| Humidity | 5% RH – 95% RH non condensing |
| Drop Specification | Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range |
| Multiple 2.4 m / 7.87 ft. drops (at least 20 times) to the concrete after installed rubber bumper | |
| Tumble Specification | 1000 x 0.5 m / 1.64 ft. falls at room temperature |
| Sealing | IP65 per IEC sealing specifications |
| ESD | ±15 KV air discharge, ±8 KV conductive discharge |
| Barcode Scanning (Optional) | |
| 2D Scanner | Zebra: SE4710/SE2100; Honeywell: N6603; E3200; IA166S |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc. |
| UHF1 (Optional) | |
| Engine | CM710-1 module based on Impinj E710 CM2000-1 module based on Impinj Indy R2000 |
| R/W range | Up to 15 m (open outdoors, Impinj MR6 tag) |
| Fingerprint (Optional, only Android 11) | |
| Sensor | Capacitive TCS1 |
| Volume Measurement (Optional, only Android 11) | |
| Measured distance | 40m-4m |
| Vo-LTE | Support Vo-LTE HD video voice call |
| Bluetooth | Android 9: Bluetooth 4.2/4.1+HS/4.0/3.0+HS/2.1+EDRAndroid 11: Bluetooth 5.1 |
| GNSS | GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna |
